20° Tilted 7.0 Wide” Color Touch LCD Monitor
The user could operate the equipment more convenient with full touch screen, clearer and larger screen size.
Specification
| K/R Mode | |
|---|---|
| Ref. Mode | |
| Ker. Mode | |
| CLBC Mode |
| Vertex Distance (D) | 0, 10, 12, 13.5, 15 mm |
|---|---|
| Sphere(SPH) | - 25.00 ~ + 22.00 d (0.12, 0.25 d) |
| Cylinder(CYL) | 0.00 ~ +/- 10.00 d (0.12, 0.25d ) |
| Axis | 1 ~ 180° |
| Cylinder Form | -, +, +/- |
| Pupil Distance | 10 ~ 85 mm |
| Min. Pupil Dia. | ø 2.0 mm |
| Radius of Curvature | 5.0 ~ 10.2 mm |
|---|---|
| Corneal Power | 33.00 ~ 67.50 d |
| Corneal Astigmatism | 0.00 ~ -15.00 d (0.05/0.12/0.25 d) |
| Axis | 1 ~ 180° |
| Corneal Dia. | 2.0 ~ 12.0 mm |
| Internal Printe | Thermal Printer |
|---|---|
| Display | 7.0 inch Wide Touch LCD Color Monitor |
| Power Supply | AC 100 ~ 240 V, 50/60 Hz, 90W |
| Dim./Weight | 275(W) x 525(D) x 440(H) mm / 20 Kg |
| Chinrest Mov. | Max. 65 mm |
| Data Output | RS-232 Interface, Video Output |
